Shift Lever Display for CBR 250 R CBR250R CBR 250R CBR250 R 2011 2012 2013 2014 Motorcycle Gear Indicator Speed Display Meter ECU Plug Parts

QUALITY ASSURANCE: We provide professional customer service and technical support for motorbikes. Welcome to contact us.Features:Light Color: Red1-6 Level Gear displayFitment:For CBR250R 2011-2014Confirmation:1. Separate Speed Sensor connector (you might need to use a small flathead screwdriver to get connector apart).2. After separating Speed Sensor connector, plug in both male and female 3-pole GFYSHIP harness connectors. Make sure connectors are fully seated.3. Find wire that comes from Signal generator (Pickup coil / CKP sensor).4. Connect Green wire to this wire, using Red wire tap connector supplied.( green wire is connected to crankshaft sensor signal line)Setup:You need to setup module after installation. When ignition is turned on, display counts backwards (6 to 1) indicating that memory is clear.Raise rear wheel off ground by using a stand, and start engine in Neutral. When gear indicator screen displays ''L'', it means to start learning; Slowly accelerate through throttle handle,When gear indicator displays ''1'', please select first gear, display is blinking faster while unit is learning gear,release clutch, and keep RPM above idle speed;When gear indicator displays ''2'', please select second gear;Repeat this process until all gears are thought (5 or 6). unit is programmed and should indicate gears correctly.Now, when ignition is turned on, display counts forward (1 to 6) indicatingthat it is fully functional. steps to reset product:Turn on key switch of switch lock. When gear indicator shows 3, turn off key switch of switch lock immediately, and then turn on key switch of switch lock immediately. According to above , turn on and turn off key switch of switch lock six times in a row to see if reset is complete(When ignition is turned on, display counts backwards (6 to 1) Indicates that memory has been cleared). Package List:1 x Motorcy

• Welcome to our motorbike parts shop, if you have any difficulties in purchasing motorbike products, you can contact us at any time, we will solve the problem in the shortest possible time!
• Application: For CBR 250 R CBR250R CBR 250R CBR250 R 2011 2012 2013 2014 Motorcycle Gear Indicator Display
• ： gear display shows gears of 1-6 steps are made of plastic, and resistant to high and low temperature, Sturdy in use.
• Function：With this digital gear indicator, let you stop guessing what gear you're in, just with a single glance on display.
